The Gateway That Broke and the Expensive Models We Didn't Need
FreeLLMAPI had been quietly routing a small agent swarm across more than a dozen providers. Then the setup collapsed to four, its premium credential vanished, and activation started failing. Recovering it taught me that the real upgrade was not a pricier model. It was one source of truth and intentional routing.
Process note: Human-directed, AI-assisted investigation, writing, and illustration.
I maintain a small agent swarm that researches, drafts, codes, and reviews. Its model traffic passes through FreeLLMAPI, a local gateway that turns many provider credentials into one endpoint and model catalog.
For months it just worked. I remembered setting up somewhere between fourteen and seventeen providers, activating the premium gateway credential, and watching the swarm fall through free tiers when one provider was slow or exhausted. It became infrastructure in the most dangerous sense: reliable enough that I stopped thinking about how it worked.
Then I opened it and found four providers.
The FreeLLMAPI credential inside the tool was gone. Trying to activate it again returned a 400. The rest of my environment was intact, but the gateway had been hollowed out. Agents that depended on its catalog and fallback routes suddenly looked misconfigured.
Two working installations made one broken system
The failure was not a dramatic database crash. It was worse: a believable partial system.
FreeLLMAPI had been split between a Docker build and a native build. Each had its own database state. The native process was alive and serving requests, but it had the four-provider version. The older, richer state, including the active premium credential and the provider inventory I remembered, still existed on the Docker side. The activation request failed because I was asking one runtime to recognize state that belonged to the other.
Both installations were plausible. Together they had no source of truth. Depending on which database you inspected, FreeLLMAPI was licensed or unlicensed, rich in providers or reduced to four.
That is how configuration drift becomes an outage without anything technically going offline.
Recover the state before redesigning the system
The tempting response was to re-enter keys from environment files and rebuild the provider list by hand. That would have produced a third interpretation of the setup. Instead I treated the databases as recovery evidence.
I compared the databases, checked their integrity, counted credentials without printing them, and reconciled the provider rows against the current build. The recovered state held 21 credential rows across 19 providers, with twenty enabled. Nineteen enabled credentials passed health checks. The premium license was still active. The setup had not disappeared; I had been looking at the wrong state store.
Only after recovery did I choose a permanent owner. A native service now owns the verified database, binds only to the local machine, restarts automatically, and writes encrypted hourly backups. Docker was retired from production.
One service. One database. One recovery path.
The curation that did more than the budget
Before consolidation, some agents used bare auto routing: whatever the gateway happened to prefer. There was no intentional curation or guard against an expensive model being selected automatically.
The fix was creating three named route selectors:
auto:smart-core: the strongest automatically routed free model pool. Every route in it had passed a live completion canary. No assumptions, no untested providers.auto:fast-core: a speed-optimized pool for routine work. Models are sorted by intelligence within the fast tier, so the best quick model wins.fusion:smart-core: a synthesis route for editorial review. Its judge is pinned to one model, and the most expensive free model is explicitly excluded from the automatic pool.
The key rule: Hyper DeepSeek V4 Pro and any paid Nous model are manual escalation only. They never appear in a primary route, a fallback chain, a Fusion panel, or an automatic judge. I can still use them when a task genuinely needs the extra capability, but it has to be a deliberate choice, not a silent default.
The same agents, suddenly smarter
Once the routes were named and curated, I assigned them:
- Atlas, Hive, and Beau, the research and dispatch agents, got Hyper DeepSeek V4 Flash as their primary, with
auto:smart-coreand NVIDIA GPT-OSS as fallbacks. - Builder, the implementation agent, uses a free MOA blend that composites multiple free models, with
auto:fast-coreand V4 Flash as fallbacks. - Honey, the editorial agent, uses V4 Flash with Fusion as its review/fallback layer.
The smartest discovery: Hive is the sole continuous dispatcher for the swarm's task board. Atlas is the standby if Hive is taken offline. One agent polls, the rest do one-shot work. This rule alone eliminated the most common failure mode in a multi-agent system: competing dispatchers stepping on each other.
The lesson worth stealing
I thought the swarm needed a paid model budget. It needed a receipt audit: find what I already had, verify it, and route it intentionally.
- Inventory before you buy. The credential you already have, tested and routed, beats the one you're about to sign up for. I had 19 healthy credentials and didn't know it.
- A named selector beats bare auto.
auto:smart-corepreserves intent even if the dashboard's active profile changes. Bareautois a gamble on whatever the gateway happens to prefer today. - Exclude the expensive ones on purpose. If a paid model isn't your primary, it shouldn't be in your automatic fallback either. Manual escalation is the cheapest way to keep a pro model available without letting it burn through your budget by accident.
- One dispatcher per board. The most reliable agent is the one that isn't competing. Pick one, name a standby, and enforce the rule.
